BBM-4500 Series
The BBM-4500 is a heavy duly pipe beveling machine which is designed for beveling pipe, tube facing and weld age preparation for heavy wall thickness tubes. Modular and ergonomic design.
Drive |
- |
Pneumatic |
Electric |
Locking Range |
MM |
35 - 105 |
35 - 108 |
Idal Speed |
RPM |
80 |
70 |
Torque |
NM |
145 |
140 |
Feeding Stroke |
MM |
40 |
40 |
Pneumatic Power |
HP |
- |
1.35 |
Air Consumption |
CFM |
- |
55-60 |
Air Pressure |
BAR (PSI) |
- |
6(90) |
Air Hose Connection |
BSP |
- |
1/2" |
Electric Motor Power |
WATT |
1000 |
- |
Voltage |
VOLT |
220/110 |
- |
Frequency |
Hz |
50 |
- |
Max Noise Level |
dB |
75 |
75 |
Unit Weight |
KG |
10.5 |
9.5 |
